Specifications
-
DC voltage: 500V
- basic accuracy: ± 0.8%
- input impedance: > 9Mohm
- maximum input: 500V
-
AC voltage: 750V
- basic accuracy: ±1.0%
- input impedance: > 9Mohm
- maximum input: 500V
-
AC current: 200/1000A
- basic accuracy: ±2.0%
- overload protection: 1200A for 60 seconds
-
resistance: 200/20k (insulation test : 20M/2000M)
- basic accuracy: ±1.0% (±2.0% for insulation test)
- overload protection: 500V
- over range indication: yes "1"
- continuity buzzer: yes
- low-battery indication: yes "BAT"
- maximum display: 3 1/2 digits
- LCD display size: 0.57" x 1.86" (14.5mm x 47.2mm)
- ranging mode: manual
- data hold: yes
- backlight: no
- overall dimensions: 9.1" x 1.5" x 3.5"
- weight (with battery): ± 11.3oz
- power supply: 9V battery (included)
- packaging: retail box
- accessories: manual / test leads / battery / carrying bag
- auto power-off: no
